Line Magnetic LM-217IA
LM-217IA
Single-End Tube Amplifier
The Line Magnetic 217IA integrated amplifier operates in Class A with tubes 300B mounted in “Single-ended” and delivers a power of 2x8W. It has 3 unbalanced line inputs, a CD input and groups of 4 and 8Ω outputs. The backlit level meter on the front is used to adjust the polarization of the tubes. The use of high quality components (Realcap capacitors, potentiometer ALPS) wired in the air for the most part is the guarantee of exemplary reliability. Its output transformers are EI type designed especially for it allow to manage a very wide range of speakers. The LM-217IA delivers sound that is dynamic, rich and natural. Voice soft modes and Pure and smooth are suitable for vocals and softer music based of ropes.
Features:
1.Hand-made construction with the finest point-to-point wiring.
2.Specially designed EI transformer for power supply.
3.Two EI output transformers with wide bandwidth are applied.
4.Two 12AX7s and 12AU7s are used in the preamp stage.
5.300B tubes are used for A single ended class a power amplifier.
6.Provide the triode and superlinear selection function. Triode, voice soft, pure and smooth, suitable for appreciation vocals, string and other types of music;
7.Triode and Ultralinear selection.
8.SoftStart and time-delay circuit. (30 seconds)
9.ALPS volume control and Realcap capacitors are applied.
10.Remote control for all functions.
11.User bias control is accessible on top of the amplifiers panel with true ampere meter.
12.Convenient installation drawing plug-in valve cap
Specifications:
Power output：8W+8W（RMS Triode operation）
Frequency response：10Hz～50kHz（-1.5dB）
THD：1%（1kHz）
S/N Ratio：87dB
Input Sensitivity：180mV
Input Impedance：100kΩ
Output Impedance：4Ω ，8Ω
Tube Complement：12AX7 x2、12AU7 x2、300B x2、5U4G x1、5AR4 x1
Power supply: AC 220V 50/60Hz ±10%
Power Consumption：90W
Working Condition: Temperature: 0℃～40℃ Moisture: 20%～80%
Storage Condition: Temperature: -20℃～70℃ Moisture: 20%～90%
Dimension： W 376 x H 192 x D 345mm
Net weight: 22kg
